    PLW High Sensitivity 110K IPX8 Waterproof 40m Underwater Ranging Ultrasonic Transducer
    Model : PL050114300

    PLW High Sensitivity 110K IPX8 Waterproof 40m Underwater Ranging Ultrasonic Transducer is mainly used in the short and medium-range underwater communication, for underwater positioning and navigation, for marine environmental monitoring and scientific research and for data telemetry between underwater devices. It features 40m measuring range, strong anti-interference capability, an IPX8 waterproof rating, stable underwater data transmission, and adaptability to complex underwater acoustic environments.

    Here comes its specification :

    Resonance Frequency Fs
    (In Air)

    110kHz±5%

    Capacitance

    200PF±20%

    Minimum Impedance

    700Ω±20%

    Pressure

    ≤1PM

    Maximum Operating Voltage
    (Pulsed Wave)

    ≤400Vpp

    Waterproof Rating

    IPX8

    Operating Temperature

    -40~+80℃

    Housing Color

    Black

    Housing Material

    pps+30%gf




    And its application fields look like :

    Module PL050114300 Application Fields

    Welcome to inquire for more details! Also, customization is also acceptable!
