PLW 500KHz Waterproof 30m Measuring Range Anti-Interference 100m Pressure-Resistant Underwater Ranging Transducer

    PL060504300
    Delivery:
    EXW
    minimum order:
    2 pieces
    Supply Ability:
    10000pieces / Month
    Country of Origin:
    Guangdong, China
    Stock Time:
    15Day
    Quantity:
    Contact Now

    PLW 500KHz Waterproof 30m Measuring Range Anti-Interference 100m Pressure-Resistant Underwater Ranging Transducer
    Model : PL060504300

    PLW 500KHz Waterproof 30m Measuring Range Anti-Interference 100m Pressure-Resistant Underwater Ranging Transducer is mainly used in the Smart Marine Aquaculture, Marine Exploration and Underwater Robot Interconnection. It features strong anti-interference, IPX8 waterproof, underwater data transmission, adaptable to complex underwater acoustic environments.

    Here comes its specification :

    Resonance Frequency Fs
    (In Air)

    500kHz±5%

    Sensitivity

    Probe Driving Voltage 24V,
    Echo Amplitude 400mV at a Distance of 0.3m

    Angle

    Beam Width
    (Half-power Angle @-3dB : 4.0±10%;
    Sharp Angle : 9.5±10%)

    Pressure

    Maximum Water Depth of 100m

    Operating Voltage

    Less Than 600Vpp

    Waterproof Rating

    IPX8

    Operating Temperature

    -40~+80℃

    Housing Color

    Black

    Housing Material

    ABS




    And its application fields look like :

    Application Fields of Module PL060504300

    Welcome to inquire for more details! Also, customization is also acceptable!
